P&K 2714

Parameter of area map output

P&K 2714: Support temporary suspended for review / Unterstützung vorübergehend für Revision ausgesetzt


Draw evaluation areas, area sources, line sources and point sources

The illustration of sources and evaluation areas can be enabled for graphic output. For each element the color, the symbol (border around evaluation areas, circle for point sources, line for line sources and rectangle for area sources). the name and sometimes the line width can be enabled or modified. The button Color opens a color dialog for each object.

Long Names

If available, the defined (long) names will be displayed instead of numbers.

The form may contain different choices.
